Description
The Disabled Toilet Alarm Kit comes complete with a 12v power pack and requires a single-pair cable run from the call point to the over door light. The distance between the call point and the over door light can be up to 400 metres. The over door light includes a built-in buzzer and will continue to sound and flash until the cancel button is pressed.
The silicon call button is backlit and manufactured with anti-bacterial properties. It is available in green (“Call”), red (“Emergency”) or yellow (“Assist”). Green “Call” with a yellow over door LED is the default supply option unless otherwise requested.
A higher-level Assist alarm can be generated by pressing both the call and cancel buttons together in times of duress. An Assist alarm flashes the over door light and activates a faster buzzer cadence.
Multiple over door lights can be installed, typically one outside the toilet and another in reception. Additional over door lights are available here: Over Door Light With Piezo.
The system supports optional pendant cord connection via jack, suitable for day surgeries, dental clinics and school sick bays. Each call point also includes a 2-second momentary relay output for connection to other systems such as fire panels.
Optional configurations include wireless connectivity to pagers or annunciators, strobe lights in place of or in addition to over door lights, and latching/twist-release mushroom head call buttons.
As a hard-wired system, the call point is typically flush mounted. Surface mounting enclosures and waterproof gaskets are available. For a fully wireless solution, see our Wireless Nurse Call Self Installed systems.
See the demonstration video below.
View the Toilet Alarm Data Sheet
What specification should a disabled toilet alarm system meet in Australia?
This specification outlines the minimum requirements for a hard-wired disabled toilet alarm system in Australia, including call behaviour, wet-area protection, backup power and escalation functionality. It supports accessible toilet emergency call installations requiring reliable local and central alerting.
Minimum Requirements for a Basic Hard-Wired Toilet Facility
Call Behaviour
- Easy-to-reach call button with audible reassurance.
- Separate Call and Cancel buttons.
- Assist escalation by pressing Call and Cancel simultaneously.
Hygiene and Wet Area Protection
- Washable hygienic outer surface.
- Antibacterial/antifungal silicon buttons with optional Braille.
- Minimum IP66 waterjet protection rating.
- Waterproof surface-mount enclosure where required.
Power and Safety
- Backup power required.
- UPS-capable plug pack when locally powered.
- Pull cords positioned near floor level with 2–3 kg break safety link.
- Pull cords should be avoided where safer alternatives exist.
Alert Routing and Integration
- Hard-wired extension to central locations (e.g. reception).
- Control of multiple over door lights with piezo buzzer.
- Capability to trigger local or remote strobe/siren alerts.
- Support for slave call points (e.g. twist-release mushroom head).
Additional Requirements for Enhanced or Multi-Toilet Installations
- All basic hard-wired requirements observed.
- Integration capability with Security or Building Management Systems.
- Optional UHF long-range wireless communication.
- A wireless configured system shall also be able to support Alphanumeric Pagers and LED Annunciator displays.
Technical Requirements Summary – Toilet Alarm
| Feature | Specification |
|---|---|
| Call Buttons | Separate Call and Cancel |
| Escalation | Assist via Call + Cancel |
| Ingress Protection | Minimum IP66 |
| Backup Power | UPS capable |
| Pull Cord Safety | 2–3 kg break link |
| Alert Extension | Central location hard-wired |
| Over Door Indicators | Light + piezo buzzer |
| Integration | BMS / Security compatible |
| Wireless Option | UHF long-range supported |
Please complete the quote form below or call and speak to our sales team for more information or a written quotation.
