Bed Exit Sensor Beam – Single PIR Version 2
The Safe-Life Single Bed Exit Sensor Beam uses one PIR curtain beam to detect early bed-exit movement, triggering an immediate alert through any nurse call system in Australia. This is a reliable, non-contact option for aged-care facilities that need single-side monitoring for residents whose beds are positioned against a wall.
What is the Safe-Life Bed Exit Sensor Beam?
The system uses a passive infra-red (PIR) curtain beam to monitor when a resident begins exiting the bed. The beam runs along the bedside and tapers downward, which prevents false alarms from staff moving around the foot of the bed.
To understand how PIR sensing works, click here.
The single PIR model monitors one side of the bed, making it suited to aged-care rooms where the wall blocks exit from the opposite side. To learn more about PIR technology click here.
How does the Bed Exit Sensor Beam work?
The system projects a tapered PIR beam along the bedside. When the resident moves a leg over the edge, the beam breaks and the nurse call point is triggered instantly.
Process (Step-by-step)
-
Mount the PIR 35–40 cm above the floor at the head of the bed.
-
The PIR projects a downward-tapered beam along one bedside.
-
On power-up, the sensor self-calibrates for one minute.
-
The resident begins to exit and breaks the beam.
-
An alert is sent to the nurse call system through a 6.35 mm or 3.5 mm connector.
Who is this system best suited for?
-
Aged-care residents at risk of falls
-
Single-side bed exit monitoring
-
Rooms where beds sit against a wall
-
Facilities seeking non-contact fall prevention
-
Environments replacing bed mats or pressure pads
-
NDIS, SDA and community care settings
Key Features and Benefits
Core Features
-
Single-side monitoring: Designed for beds positioned against a wall.
-
Version 2 modular design: Uses RJ11 connectors for easy installation and future upgrades.
-
Nurse call compatibility: Works with Smart Caller, Austco, Sedco, Care Tech, Questek, Advanced Care, Xacom and all other major brands.
-
Configurable 6.35 mm or 3.5 mm plug: Mono supplied; removable lugs allow Tip & Ring, Tip & Sleeve or Ring & Sleeve setups.
-
No-contact operation: No pads, mats or consumables.
-
LED indicators: Shows arming and armed status, including a built-in 10-second arming delay.
-
Wall or stand mounting: Works with Safe-Life stands when wall fixing isn’t feasible.
-
Pendant compatibility: Use Safe-Life Double Adaptor (A-ADAP-02-S-1) for simultaneous pendant and sensor use.
Benefits for Facilities
-
Minimises false alarms caused by staff movement
-
Non-contact and hygienic
-
Easy to relocate with spare wall brackets
-
Ideal for permanent wall-mounted use or temporary installations
-
Supports long-term aged-care use cases
-
Fully repairable, reducing long-term replacement cost
Are there any real-world case studies for this product?
Yes. Safe-Life has published case studies showing how this product is used in Australian aged-care to reduce falls and improve safety.- Case Study: Bed exit sensor in a South Australian aged-care facility
How replacing floor mats with the Safe-Life Dual PIR Bed Exit Sensor reduced falls and improved hygiene.
Technical Specifications
| Specification | Details |
|---|---|
| Model | A-BEDEXIT-PIR-01-V2 (Single) |
| Technology | Passive Infra-Red curtain beam |
| Mount height | 35–40 cm |
| Connectors | RJ11 interconnects; 6.35 mm or 3.5 mm plug |
| Arming delay | 10 seconds |
| Indicators | LED flashing (arming), LED solid (armed) |
| Warranty | 4 years |
| Compatibility | All major nurse call systems |
| Mounting options | Wall brackets or Safe-Life A-STAND-01 / A-STAND-02 |
Installation Overview
Mounting
-
Install the wall-mount bracket 10 cm out from the bed and 35 cm from the floor.
-
Test alignment with Blue-Tack before final installation.
-
Lower the sensor slightly if beam extension reaches the foot of the bed.
Single Sensor Setup
-
Connect the PIR to the nurse call point using the appropriate 6.35 mm or 3.5 mm plug.
-
Plug in power via RJ11.
-
Avoid standing in front of the sensor during calibration.
Stand Mounting (optional)
-
Suitable for rooms where wall fixing isn’t ideal.
-
Adjust vertical tilt, distance and angle until walk-test confirms coverage.
-
Secure cable placement to prevent accidental misalignment.
Common Questions (FAQ)
Does this system work without mats or pressure pads?
Yes. It is fully non-contact and relies on PIR curtain detection.
Will it work with our nurse call system?
Yes. The plug ships in mono as standard but can be reconfigured using removable lugs to match your nurse call wiring.
Can a pendant cord still be used?
Yes. Use the Safe-Life Double Adaptor (A-ADAP-02-S-1).
Is this suitable for homes or community housing?
Yes. Pair the bed alarm sensor beam with a Safe-Life transmitter and pager kit.
What if the sensor is bumped?
Movement can affect beam alignment. Mark the stand footprint or recheck bracket alignment if disturbed.
Why choose Safe-Life?
Safe-Life provides fall-prevention technology trusted by Australian aged-care providers for more than 15 years. The Single Bed Exit Sensor Beam is reliable, non-contact and designed for environments that require simple installation, longevity and full serviceability.
